Low temperature chiller

The DLS series low-temperature chiller is mainly composed of refrigeration system, circulation system, control system, box, etc. The refrigeration system adopts steam compression refrigeration, and the compressor and main refrigeration components are all from internationally renowned brands, with stable and excellent performance at the outlet water temperature. The temperature control accuracy can reach ± 0.1 ℃, and optional components can achieve multi-channel output and load, which is energy-saving and environmentally friendly, and easy to operate. And it can achieve multiple alarm functions such as overheating, overload, and water shortage, making remote control convenient. It can control various communication methods such as I/O, RS232, RS485, etc

Temperature control range: -45 ℃~room temperature
Refrigeration method: steam compression refrigeration
Condensing method: air-cooled or water-cooled
Does it support customization: Yes

Consult immediately

OUR
ADVANTAGE

products

PROTECO

See the parameters clearly

Name

  • Model name
  • Main applications
  • temperature range
  • Circulating fluid
  • Control system
  • Temperature control mode
  • communication protocol
  • Temperature feedback
  • cryogen
  • Circulating pipeline
  • Alarm function
  • Shell material
  • explosion-proof
  • Other detailed parameters

Parameter Function Description

  • DLS series low-temperature chiller
  • This product is suitable for external applications that require rapid cooling, and industries such as chemical, biological, pharmaceutical, freeze-drying, food, and military industries that maintain low temperature conditions.
  • -45 ℃~room temperature
  • 15% ethylene glycol aqueous solution
  • Professional developed dedicated controller+LCD button operation screen
  • Equipment outlet temperature control
  • MODBUS RTU protocol RS 485 interface
  • Equipment thermal conductivity medium temperature feedback PT100 (inlet temperature, outlet temperature)
  • R404A
  • Adopting a fully enclosed system design, it extends the service life of thermal oil while ensuring the stability of system operation.
  • Multiple alarm protection: protection functions for thermal overload of circulating pump, compressor, high refrigeration pressure, low refrigeration pressure, overcurrent, over temperature, phase loss, phase sequence, etc
  • Cold rolled sheet spray coating (optional with SUS304 material)
  • Optional explosion-proof design (positive pressure explosion-proof model suffix Exp, isolation explosion-proof model suffix Exd)
  • For details, please consult customer service

Product recommendations

It mainly consists of refrigeration system, circulation system, control system, box, etc. The refrigeration system adopts steam compression refrigeration, and the compressor and main refrigeration components are all from internationally renowned brands. Ensure the safe operation of the equipment for external applications that require rapid cooling.

Ultra low temperature freezer
More

The DLS series low-temperature chiller is mainly composed of refrigeration system, circulation system, control system, box, etc. The refrigeration system adopts steam compression refrigeration, and the compressor and main refrigeration components are all from internationally renowned brands, with stable and excellent performance at the outlet water temperature. The temperature control accuracy can reach ± 0.1 ℃, and optional components can achieve multi-channel output and load, which is energy-saving and environmentally friendly, and easy to operate. And it can achieve multiple alarm functions such as overheating, overload, and water shortage, making remote control convenient. It can control various communication methods such as I/O, RS232, RS485, etc

Low temperature chiller
More

-135 ℃~+225 ℃, can meet the needs of different temperatures, and can be customized non-standard; Optional precise temperature control form, with a maximum temperature control accuracy of ± 0.1 ℃; Using an efficient heat exchanger, the cooling speed is fast, and it only takes 5 minutes to reach -80 ℃ at room temperature; Optional cooling capacity recovery device to improve energy efficiency and avoid low-temperature condensation water. Optional intake flow automatic control and detection

Low temperature air conditioner
More

The direct cooling refrigeration machine adopts refrigerant direct evaporation, and the cooling method is phase change refrigeration. Compared with the temperature difference cooling of liquid cooling, the cooling speed is faster, the energy efficiency is higher, the equipment has no circulation system, and the external dimensions are more compact!

Direct cooling refrigeration machine
More

OUR
SERVICE

service

PROTECO

Proteco Services

Free door-to-door delivery nationwide: The delivery time varies from 5-7 days in various provinces of northwest, northeast, and southwest. Due to uncertain factors, the delivery time in some places is more than 7 days, while in other provinces it is 3-5 days. The delivery time in Jiangsu, Zhejiang, and Shanghai is 1-2 days

We do not make any promises regarding transportation time. In the event of holidays, rain, snow, heavy fog, etc., there may be occasional delays in logistics transportation, which is beyond the manufacturer's control. Please understand.

  • Complete order
  • Print invoice
  • Packaging and packing
  • Free logistics
  • Free installation/debugging
